Z-Carb MD | Series ZD1

p
h

The patented unequal high helix of the Z-Carb MD reduces damaging harmonics by changing the angle at which each cutting edge enters and exits the material. Combined with unequal flute spacing and a heavy core, this end mill effortlessly machines hardened steels with incredible tool life.

View Products
Where to Buy
Z-Carb MD Group Tool Picture

Features

Rake

Negative rake Icon
  • The original Z-Carb design with a negative rake, heavy core, and higher helix for strength and shearing of hard mold & die materials.

Corner

End corner radius icon
  • Enhanced corner geometry with tight tolerance corner radii.

Fluting

Unequal flute spacing Icon
  • Unequal flute spacing helps to disrupt the rhythmic pattern created by the cutting edge helping to suppress damaging harmonics.
Coatings
Ti-namite-x Logo
  • The structural design of Ti-Namite-X is adapted to meet a diverse range of applications; everything from high- and low-alloy steels to hardened materials (up to 65 HRC core hardness). Ti-Namite-X is suitable for operations that require high cutting speeds, high temperatures at the cutting edge, and high metal removal rates.
Z-Carb MD white line drawing

Series Details

Lineup Details

  • Cutting Diameter 1/8"-3/4" | 3,0 mm - 20,0 mm
  • Length of Cut 5/32"-15/16" | 4,0 mm - 24,0 mm
  • Overall Length 2 1/2"-5 1/2" | 57,0 mm - 104,0 mm
  • Shank Diameter 1/4"-3/4" | 6,0 mm - 20,0 mm
  • Reach 1/2"-3 1/4" | 15,0 mm - 55,0 mm
  • Corner Radius .010 - .060 | 0,20 mm - 2,0 mm
  • Coating(s) Ti-NAMITE-X

Primary Material Applications

  • Cast Iron ≥ 45 HRc
  • Hardened Steels < 45 HRc
  • Hardened Steels > 55 HRc

Industry Applications

Aerospace icon

Aerospace

Medical icon

Medical

Power generation icon

Power Generation

automotive icon

Automotive

Mold and Die icon

Mold & Die

Casting and foundries icon

Casting & Foundries

General engineering icon

General Engineering

Secondary Material Applications

  • Steel ≤ 45 HRc
  • Cast Iron ≤ 45HRc

Resources

Download

Aerospace Machining Solutions brochure cover image

Aerospace Machining Solutions

Download

Tool matrix brochure cover image

Tool Matrix

Download

Z-carb MD speed and feeds brochure cover image

Z-Carb MD

Speeds / Feeds

Turbine blade manufactured on a 5th axis CNC machine and an end mill.

SALES SUPPORT

Need help with an application or require sales assistance? Our field sales engineers can help you find the right solution for the job.
