OPTIMAL

REMOVAL

RATES

Z-Carb Logo

Z-Carb | Series Z1

P
M
K
S

Z-Carb four-flute high performance end mills set the standard for optimal removal rates. With unparalleled efficiency and performance, these legendary tools have been upgraded with enhanced geometry.

View Products
Where to Buy
3 Z-Carb End Mills Grouped

Features

Radial Rake

Unequal Flute Spacing Diagram
  • Unequal flute spacing helps to disrupt the rhythmic pattern created by the cutting edge helping to suppress damaging harmonics.

Ball End and Material Removal

Ball end end mill
  • The ball end design is ideal for finishing operations in complex workpieces.
  • Achieve optimal material removal rates with the Z-Carb end mills through increased feed and depths of cut.

Helix

End mill helix and flute diagram
  • Unequal helix design reduces damaging harmonics by changing the angle at which each cutting edge enters and exits the material.
Coatings
Ti-NAMITE-X logo
  • The structural design of Ti-Namite-X is adapted to meet a diverse range of applications; everything from high- and low-alloy steels to hardened materials (up to 65 HRC core hardness). Ti-Namite-X is suitable for operations that require high cutting speeds, high temperatures at the cutting edge, and high metal removal rates.
White drawing of Z-Carb End Mill

Series Details

Lineup Details

  • Cutting Diameter: 1/8"-1" | 3,0 mm - 25,0 mm
  • Length of Cut: 3/8"-1 1/2" | 8,0 mm - 38,0 mm
  • Overall Length: 1 1/2" -4" | 57,0 mm - 104, 0mm
  • Shank Diameter: 1/8"-1" | 6,0 mm - 25,0 mm
  • Corner Radius: .015"-.040"
  • Coating(s): Ti-NAMITE-X
  • Available Features: JetStream, Weldon Flat

Primary Material Applications

  • Steel ≤ 45 HRc
  • Stainless Steel ≤ 45HRc
  • Cast Iron ≤ 45HRc
  • High Temp Alloys
  • Titanium Alloys ≤ 45 HRc

Industry Applications

aerospace

Aerospace

medical icon

Medical

Power generation icon

Power Generation

Automotive icon

Automotive

Mold and die icon

Mold & Die

Casting and foundries icon

Casting & Foundries

General engineering icon

General Engineering

Secondary Material Applications

  • Cast Iron ≥ 45 HRc
  • Hardened Steels < 45 HRc

Resources

Download

Aerospace Machining Solutions brochure cover

Aerospace Machining Solutions

Download

Tooling Matrix brochure cover

Tooling Matrix

Z-Carb | Z1B

Speed / Feed

Z-Carb | Z1MB

Speed / Feed

Turbine blade manufactured on a 5th axis CNC machine and an end mill.
