ADVANCED

PRODUCTIVITY

FINISHER

S-Carb APF

The S-Carb Advanced Productivity Finisher (APF) is a four-flute unique variable geometry finishing end mill. The APF outperforms the traditional waterline method of thin-wall machining by over 60 times, with straighter and thinner walls. The APF is the authority in aerospace aluminum finishing and has set the global standard for part quality, cost, and tool life. The KSPT Advanced Productivity Aluminum program has redefined what is possible in aluminum machining with the APF and its sibling tool the APR.

View Products
Download Brochure

Features

Flutes

  • 4-Flute unique variable geometry reduces vibration and allows the finishing of thin walls in one pass.
  • Polished flutes maximize chip evacuation and provide an enhanced finish.
Through Coolant Options
  • Central hole delivers coolant effectively to the cutting zone.
  • Enhances chip removal when pocketing or slotting.
  • Select fractional and metric diameters in stock.

Design

  • The S-Carb APF is engineered with a positive rake.
  • Designed for single-axial pass semi-finishing and finishing.
  • Two levels of chatter suppression: variable helix and indexing.
  • Ultra high-productivity finisher for Aluminum alloys, specifically for aircraft components.
Coatings
  • This ceramic-based coating ensures a smooth surface and a low affinity to cold welding or edge build-up, which makes it optimal for aluminum and copper applications. It has high toughness and high hardness.

Series Details

Lineup Details

  • Cutting Diameter: 1/2"-3/4" | 6,0 mm - 25,0 mm
  • Length of Cut: 1 1/4"-3" | 24,0 mm - 100,0 mm
  • Overall Length: 3 1/4"-5 3/8" | 58,0 mm - 175,0 mm
  • Shank Diameter: 1/2"-3/4" | 6,0 mm - 25,0 mm
  • Reach: 1 5/8"-3 1/2" | 30,0 mm - 120,0 mm
  • Corner Radius: .030-.120 | 2,0 mm - 5,0 mm
  • Coating(s): Ti-NAMITE-B
  • Special Options: JetStream Technology

Primary Material Applications

  • Non-Ferrous

Industry Applications

Aerospace

Medical

Power Generation

Automotive

General Engineering

Secondary Material Applications

  • Cast Iron ≥ 45 HRc
  • Hardened Steels < 45 HRc
