HIGH-PERFORMANCE

NON-FERROUS

MILLING

S-carb Logo

S-Carb | Series 43 and 47

n

The original symmetrical flute design features and engineered flute form that provides high-performance results through a full range of machining conditions. These tools are designed for aggressive aluminum, non-ferrous, and non-metallic machining requiring a high level of material removal. The S-Carb family encompasses the 2-Flute Series 47, 3-Flute Series 43, 3-Flute Advanced Productivity Rougher (APR) and 4-Flute Finisher (APF).

View Products
Where to Buy
S-Carb Non-Ferrous End Mill group image

S-Carb | Series 43

S-carb end mill image 1

Engineered Flute Design

  • Effective chip removal at high feed rates.
  • Lower cutting forces than comparable products.
  • Improved balance at high spindle speeds.
  • Improved workpiece finish.
  • More effective plunging and profiling compared to conventional designs.

Circular Land

  • Increased control at a wide range of speeds and feed levels.
  • Reduced chatter.

Various Reach, Neck, and End Options Available

  • Ball end design for complex workpieces.
  • Necked design with blended diameter transitions provides clearance to reach.
  • Short flutes for maximum rigidity.
  • Axial slotting up to 1xD.
  • All S-Carb products are available in either inch or metric configurations.
  • Available with Ti-NAMITE-B ceramic-based coating with industry-leading built-up edge protection.
Square corner icon
Corner Radius icon
Ball nose icon
Chip breaker icon
Shank length icon
helix angle icon
Positive Rake icon
3 flute end mill icon

S-Carb | Series 47

S-carb end mill image 2

Engineered Flute Design

  • Symmetrical end gashing for excellent balance at high speeds and aggressive plunging capability.
  • Open fluting for deep slotting and profiling.
  • 2-Flute design for large chip size and volume.

Circular Land

  • Increased control at a wide range of speeds and feed levels.
  • Reduced chatter.

Various Reach, Neck, and End Options Available

  • Ball end design for complex workpieces.
  • Necked design with blended diameter transitions provides clearance to reach.
  • Short flutes for maximum rigidity.
  • Axial slotting up to 1xD.
  • All S-Carb products are available in either inch or metric configurations.
  • Ti-NAMITE-B ceramic-based coating with industry-leading built-up edge protection.
Square Corner radius icon
Ball nose end mill icon
chip breaker end mill icon
shank length icon
helix angle icon
Positive rake icon
2 flute end mill icon
S-carb end mill white line drawing

Series Details

Lineup Details | Series 43

  • Cutting Diameter: 1/8"-1" | 3,0 mm - 25,0 mm
  • Length of Cut: 5/32"-4 1/8" | 4,5 mm - 80,0 mm
  • Overall Length: 1 1/2"-7" | 52,0 mm - 150,0 mm
  • Shank Diameter: 1/8"-1" | 6,0 mm - 25,0 mm
  • Reach: 1/2"-4 3/8" | 10,0 mm - 126,0 mm
  • Corner Radius: .010-.250 | 0,3 mm - 4,0 mm
  • Coating(s): Ti-NAMITE-B

Lineup Details | Series 47

  • Cutting Diameter 1/8"-1" / 3,0-25,0
  • Length of Cut 3/8"-2" / 8,0-44,0
  • Overall Length 1 1/2"-6" / 38,0-150,0
  • Shank Diameter 1/8"-1" / 3,0-25,0
  • Reach (where applicable) 2 1/8"-3 3/8" / 54,0-80,0
  • Coating(s) Uncoated, Ti-NAMITE-B

Industry Applications

aerospace icon

Aerospace

medical icon

Medical

Power generation icon

Power Generation

automotive icon

Automotive

Mold and Die icon

Mold & Die

Casting and Foundries icon

Casting & Foundries

General Engineering icon

General Engineering

Primary Material Applications

  • Non-Ferrous
  • Plastics / Composites
