8.00mm Dia, 4 Flute, Router - 82992
SERIES: 25M
Series 25 - CFRP Compression Router
8.00mm Dia, 25.00mm LOC, 63.00mm OAL, 8.00mm Shank Dia, 4 Flute, 30 Degree Helix, Uncoated, Series 25M, Series 25 - CFRP Compression Router - 82992
Feature & Benefits
Left Hand Helix
Right Hand Helix
| Series Description | Series 25 - CFRP Compression Router |
|---|---|
| High Performance | Yes |
| End Configuration | Square End |
| Tool Length | Long |
| Unit (inch/mm) | mm |
| Number of Flutes | 4 |
| Primary Workpiece Material | (N) Non-Ferrous Materials |
| Cutting Diameter (DC) (Decimal Inch) | 0.3150 |
| Cutting Diameter (DC) (mm) | 8.00 |
| Shank Diameter (DCON) (Decimal Inch) | 0.3150 |
| Shank Diameter (DCON) (mm) | 8.00 |
| Length of Cut (APMX) (Decimal Inch) | 0.9843 |
| Length of Cut (APMX) (mm) | 25.00 |
| Overall Length (LF) (Decimal Inch) | 2.4803 |
| Overall Length (LF) (mm) | 63.00 |
| Shank Length (LS) (Decimal Inch) | 1.4957 |
| Split Length (SPTL) (Decimal Inch) | 0.2197 |
| Split Length (SPTL) (mm) | 5.58 |
| Cutting Diameter (DC) Tolerance (Decimal Inch) | +0.0000/-0.0030 |
| Cutting Diameter (DC) Tolerance (mm) | +0.000/-0.080 |
| Shank Diameter (DCON) Tolerance (ISO) | h6 |
| Shank Type | Straight |
| Coolant Option | External Coolant |
| Additional Geometry | Right Hand Cut Direction (RHC) |
| Rake Angle | Positive |
| Helix Angle | Right Spiral |
| Helix Angle (Degree) | 30 |
| Variable Helix | No |
| Center Cutting | Yes |
| Chip Breaker | No |
| Shipping Weight | 0.0920 |
| Series | 25M |
| US Stock | 6 |
| Shank Length (LS) (mm) | 37.99 |
| Coating Description | Bright/Uncoated |
| Flute Type | Spiral |
Alternate Products
8.00mm Dia, 25.00mm LOC, 63.00mm OAL, 8.00mm Shank Dia, 4 Flute, 30 Degree Helix, Di-NAMITE (Diamond) Coated, Series 25M, Series 25 - CFRP Compression Router - 82993
U.S. stocked items ship next day
Total Available U.S. :2
