PRECISION

FLAT BOTTOM

HOLEMAKING

Hi-PerCarb® Series 146U / 136U Logo

Hi-PerCarb® | Series 146U / 136U

P
M
K
N
S
H

The SGS Hi-PerCarb® Series 146U and 136U flat bottom drills provide a robust solution to a variety of challenging holemaking applications in the automotive, agriculture, oil and gas, and general machining industries. Whether drilling conventionally, on angled or curved surfaces, cross or intersecting holes, unique features of the SGS design combine to produce precise, high-quality holes, with minimal breakout bur.

View Products
Where to Buy
Series 146U 136U End Mill Group Picture

Features

Hi-PerCarb® Series 146U / 136U Flat Bottom Drill End Geometry Image

ECCENTRIC 4-MARGIN DESIGN

  • A unique coolant channel design allows repositioning of the trailing margins for improved stability over conventional two and four margin drills
  • Eccentric style clearance reduces margin contact with the workpiece without reducing strength

END GEOMETRY

  • The primary only relief allows the trailing margins to help stabilize the drill up to three times faster than conventional designs
  • High shear corner geometry minimizes exit bur
  • Computer controlled edge hone protects against edge chipping in difficult applications

COOLANT CHANNELS

  • The two-channel design provides additional coolant in the hole when thru-tool coolant is not available

Coating

Ti-Namite-x hard coating logo

Combine to minimize material adhesion and maximize wear resistance in a wide range of workpiece materials.

Series Details

Lineup Details

  • Cutting Diameter: 1/8"-13/16" | 3,0 mm - 20,00 mm
  • Length of Cut: 9,0 mm - 62,0 mm
  • Overall Length: 55,0 mm - 150,0 mm
  • Flute Length: 13,0 mm - 93,0 mm
  • Shank Diameter: 6,0 mm - 22,0 mm
  • Shank Length: 34,0 mm - 52,0 mm
  • Coating: Ti-NAMITE®-X


Primary Material Applications

  • Steel ≤ 45 HRc
  • Stainless Steel ≤ 45HRc
  • Cast Iron ≤ 45HRc
  • Cast Iron ≥ 45 HRc
  • High Temp Alloys
  • Titanium Alloys ≤ 45 HRc
  • Non Ferrous
  • Plastics / Composites
  • Hardened Steels < 45 HRc
  • Hardened Steels > 55 HRc

Industry Applications

General Engineering Icon

General Engineering

Casting and foundries Icon

Casting & Foundries

Mold and Die Icon

Mold & Die

Automotive Icon

Automotive

Power Generation Icon

Power Generation

Medical Icon

Medical

Aerospace Icon

Aerospace

Firearms Icon

Firearms

Resources

Download

Series 146U / 136U Brochure cover image

Series 146U / 136U Brochure

Download

Drilling Solutions Brochure cover image

Drilling Solutions Brochure

Download

Tooling Matrix Brochure Cover Image

Tooling Matrix Brochure

Download

Hi-PerCarb® Series 146U / 136U Speed and Feed brochure cover image

Series 146U / 136U Speeds & Feeds
