Coarse Cut Carbon Composite Routers | Series 31 & 31M

n

KSPT carbon composite routers were designed for maximum performance in CFRP materials. We partnered with a leading aerospace company to launch the original Series 20, a design focused on trimming and finishing in demanding applications requiring minimal fiber breakout and delamination. The addition of the Series 31 geometry adds the benefit of fewer and deeper flutes than the original Series 20 CCR to avoid clogging during heavy routing CFRP applications

View Products
Where to Buy
carbon composite routers group picture

Features

Flutes

End Mill Icon
  • 5-10 flute options available.
  • Fewer, deeper flutes to prevent clogging in heavy routing.
  • Left-hand flutes engineered to control the fibers within CFRP, preventing excessive fiber breakout.

Design

Chip Breaker End Mill Icon
  • Features chipbreakers for optimal chip removal.
  • Unique clearance grind minimizes contact between tool diameter and workpiece eliminating friction.
  • Excels at trimming and profiling difficult and abrasive fiber filled plastics.

Coatings

Di-namite Logo
Ti-Namite-b coating logo
  • This is the hardest coating available with the best abrasion resistance. It is carbon based so it is limited in application capabilities. This coating is suitable for machining highly abrasive, non-ferrous materials such as CFRP and graphite.
  • This ceramic-based coating ensures a smooth surface and a low affinity to cold welding or edge build-up, which makes it optimal for aluminum and copper applications. It has high toughness and high hardness.
Coarse Cut Carbon Composite Routers white line drawings

Series Details

Lineup Details

  • Cutting Diameter: 1/4"-1/2" | 6,0 mm -12 mm
  • Flute Length: 1"-1 1/2" | 25,0 mm - 38,0 mm
  • Overall Length: 2 1/2"-3 1/2" | 63,0 mm - 89,0 mm
  • Shank Diameter: 1/4"-1/2" | 6,0 mm - 12,0 mm
  • Number of Flutes: 5-10
  • End Style: No End Cutting, End Cutting
  • Coating(s): Di-NAMITE, Ti-NAMITE-B, Uncoated

Primary Material Applications

  • Plastics / Composites

Industry Applications

Aerospace Icon

Aerospace

Medical Icon

Medical

Power generation Icon

Power Generation

automotive Icon

Automotive

Mold and die Icon

Mold & Die

Casting and foundries Icon

Casting & Foundries

General Engineering Icon

General Engineering
